1756-EN2TR Allen Bradley allen bradley safety plc touch screen

1756-EN2TR Allen Bradley allen bradley safety plc touch screen

Products - Allen Bradley PLC
  • Highlight

    Allen Bradley PLC safety module

    ,

    1756-EN2TR PLC communication module

    ,

    Allen Bradley touch screen PLC

  • Temperature Range
    -20°C To 60°C
  • Application
    Machine
  • Part Numbe
    1769-PA2
  • Feature
    Stable
  • Digital Outputs
    32
  • Communication Protocol
    Ethernet/IP, Modbus/TCP
  • Communication Ports
    2 Ethernet, 1 Serial
  • Inputs
    Digital, Analog, High-speed Counter
  • Warranty
    12 Months
  • Place of Origin
    USA
  • Brand Name
    Allen Bradley
  • Model Number
    1756-EN2TR
  • Minimum Order Quantity
    1
  • Supply Ability
    99+

1756-EN2TR Allen Bradley allen bradley safety plc touch screen

  • 1756-EN2TR Allen Bradley allen bradley safety plc touch screen
  • 1756-EN2TR Allen Bradley allen bradley safety plc touch screen
Get Price Contact Now
1756-EN2TR: Allen-Bradley ControlLogix Ethernet/IP Bridge Module​
The 1756-EN2TR is a high-performance Ethernet/IP bridge module designed by Allen-Bradley, a leading brand under Rockwell Automation. It is specifically engineered for integration with the ControlLogix 5570/5580 programmable automation controller (PAC) platform, serving as a critical communication interface to connect ControlLogix systems to Ethernet/IP networks. This module enables seamless data exchange between the controller and other Ethernet/IP-compatible devices, making it an essential component in industrial automation environments that require reliable, high-speed network connectivity.

Technical Specifications​
​
Parameter​




Details​




Form Factor​




1756 ControlLogix chassis-mounted module (single slot)​




Ethernet Ports​




2 x 10/100/1000 Mbps Gigabit Ethernet (RJ45), auto-sensing​




Protocol Support​




Ethernet/IP (explicit/implicit messaging), SNMPv1/v2c/v3, DLR​




Operating Voltage​




5V DC (powered by ControlLogix chassis)​




Operating Temperature​




0°C to 60°C (32°F to 140°F)​




Storage Temperature​




-40°C to 85°C (-40°F to 185°F)​




Humidity​




5% to 95% (non-condensing)​




Certifications​




UL, CSA, CE, ATEX, IECEx (for hazardous locations, where applicable)​




Software Compatibility​




Studio 5000 Logix Designer v21 or later​







​
Advantages Over Competing Modules​
Compared to other Ethernet/IP modules in the ControlLogix family (e.g., 1756-EN2T), the 1756-EN2TR offers several key advantages:​
  • Gigabit Ethernet Speed: The 1000 Mbps ports provide faster data transfer rates than the 10/100 Mbps ports of the 1756-EN2T, making it ideal for high-bandwidth applications.​
  • Enhanced Security: Advanced security features (e.g., 802.1X, TLS) provide better protection against cyber threats compared to older modules.​
  • Improved Redundancy: Tighter integration with ControlLogix redundancy systems ensures faster failover and higher availability for critical applications.​
  •
